NHP MOD6RCCB46330

RCCB MOD6 3P+N 63A 30MA TYPE AC

$139.12 ex. GST.

RCCB MOD6 3P+N 63A 30MA TYPE AC

SKU: NHP MOD6RCCB46330 Category:
Height Width
86 mm 72 mm

Features

MOD6 RCCB, 4P, 6kA, 30mA, 63A

Weight 0.0000 kg
RCD Type, AS/NZS 61008/61009

AC

IΔc, Rated Conditional Residual Short-Circuit Current [kA]

6

Tripping Time at IΔn, Instantaneous [ms]

<40

In, Rated Current at 30°C [A @30°C]

63

IΔn, Rated Leakage Current [mA]

30

Neutral Pole Protected

No

Number of Poles

4

Poles

3P + N

Icn, Rated Short Circuit Capacity [kA]

6

Un, Nominal Operational Voltage, AC [V AC]

415

Mounting

DIN-35 Rail Mount

Impulse Withstand Test Voltage [kV]

6

Ui, Rated Insulation Voltage @ Pollution Degree 2 [V]

500

Height [mm]

86

Width [mm]

72

Depth [mm]

76

Ubmin, Service Voltage, AC, Min [V AC]

287

Ubmax, Service Voltage, AC, Max [V AC]

455

Selectivity Class (IEC 60898)

A

Im, Rated Make/Break Capacity [A]

500

Rated Frequency

50 / 60 Hz

IΔm, Rated Residual Make/Break Capacity [A]

500

Warranty starts from invoice date.

Warranty period: 0

Warranty method:
