PIR 7/067-2EBK/200M

2.5MM 2C AND ECC TPS BLACK 200m DRUM

$1.82 ex. GST. per metre

3X2.5mm2 + E Varolex Black, 2.5 mm² Conductor cross-section, 14.6 mm Nominal overall diameter

SKU: PIR 7/067-2EBK/200M Category:

Features

  • Stranded Copper conductors, 90°C
  • 3 core+3 earths
  • Copper tape screened
  • Intended for fixed variable speed drive applications
  • PVC sheathed to AS/NZS 5000.1
  • 0.6/1kV X-90 insulated
  • PVC bedded

3X2.5mm2 + E Varolex Black

Weight 0.0000 kg
Conductor flexibility

Class 2

Conductor material

Copper

Conductor shape

Circular

Insulation

X-90

Material of bedding

PVC filler

Outer sheath

PVC

Screen

Copper tape

Type of conductor

Stranded

Approximate weight

32.0 kg/100m

Combined earth size section

2.5 mm²

Conductor cross-section

2.5 mm²

Diameter over screen

10.9 mm

Nominal insulation thickness

0.7 mm

Nominal overall diameter

14.6 mm

Number of cores

3

Number of earth cores

1

Capacitance (All Main Cores - Screen)

0.36 µF / km

Capacitance (One Main Core - Other & Screen)

0.199 µF / km

Capacitance 3 phase operating

0.24 µF / km

Conductor AC resistance at 50 Hz

9.45 Ohm/km

Inductive reactance at 50Hz

0.097 Ohm/km

Insulation resistance at 20°C

695 MOhm.km
